Other Features |
| Detector size | 120 x 120 |
| Detector type | Uncooled microbolometer, focal plane array |
| Field of view (FOV) | 17º horizontal x 17º vertical |
| Spatial resolution (IFOV) | 2.5 mrad |
| Minimum focus distance | 15 cm (approx. 6 in) |
| Thermal sensitivity (NETD) | ≤0.1 °C at 30 °C (100 mK) |
| Detector data acquisition/ ###Image frequency | 9 Hz |
| Focus | Manual, 1-hand focus |
| IR digital zoom | No |
| Spectral band | 7.5 µm to 14 µm |
| Transmission correction (On Imager) | No |
| Reflected background temperature correction (On Imager) | In software only |
Measurement modes |
| Centerpoint | Yes |
| Center box (area, min/max, average) | In software only |
| User defined spots/boxes | In software only |
| Advanced on-board analysis functions | No |
| User defined field/text annotations | No |
| Voice annotation | No |
| Automatic hot and cold spots | In software |
Image presentation |
| Digital display | 3.6" High Resolution LCD |
| Video output | No |
| Palettes | 3 |
Optional lenses |
Image and data storage |
| Storage medium | SD memory card (2 GB), stores at least 1200 fully radiometric (.is2) IR-Fusion images or 3000 basic IR images (.bmp or .jpg) |
| On imager file formats | BMP, IS2 |
| File formats supported in software | BMP, JPG, GIF, PNG, TIF, WMF, EXIF and EMF |
Imager features |
| Fully radiometric | Yes |
| Flash and torch light | No |
| Laser pointer | No |
| Windows based navigation menu | Yes |
| AutoCapture (Programable Image Capture) | No |
| Software included | Yes (SmartView) |
Environmental and mechanical design |
| Operating temperature | -10 to °C (14 °F to 122 °F) |
| Storage temperature | -20 to +50°C (-4 °F to 122 °F) without batteries |
| Relative humidity | 10% to 90% non-condensing |
| Water and dust resistant | IP54 |
| Weight (including batteries) | 1.2 kg (2.65 lb) |
| Camera size (HxWxD) | 0.27 x 0.13 x 0.15 m (10.5 in x 5 in x 5 in) |
| Warranty | 2 years |
Power |
| Battery type | NiHM Rechargeable batter pack |
| Battery operating time | 3-4 hours continuous |
| Battery re-charge time | 2 hours for full charge |
| AC operation (110/220 VAC, 50/60 Hz) | Yes |
| Automatic shut down | Yes |
| Sleep mode | Yes |
Applications |
| In plant electrical | No |
| Electromechanical | No |
| Mechanical systems | No |
| Process monitoring and installations | No |
| Building diagnostics | Yes |
| Electronics | No |
IR-Fusion Technology |
| IR-Fusion technology | No |
| Full thermal | Yes |
| Full visual light | No |
| AutoBlend™ | No |
| Picture in picture | No |
| Color alarm | No |
Temperature measurement |
| Temperature range | -20 ˚C to 150 ˚C (-4 ˚F to 212 ˚F) |
| High temperature option | No |
| Accuracy | ±5 °C or 5% whichever is greater |
| Emissivity correction | In software only |
