Other Features |
| Detector size | 160 x 120 |
| Detector type | Uncooled microbolometer, focal plane array |
| Field of view (FOV) | 22.5º horizontal x 31º vertical |
| Spatial resolution (IFOV) | 3.39 mRad |
| Minimum focus distance | Focus-free 1.2m and beyond |
| Thermal sensitivity (NETD) | ≤0.1 °C at 30 °C (100 mK) |
| Detector data acquisition/ ###Image frequency | 9 Hz |
| Focus | Focus-free 1.2m and beyond |
| IR digital zoom | No |
| Spectral band | 7.5 µm to 14 µm |
| Transmission correction (On Imager) | No |
| Reflected background temperature correction (On Imager) | Yes |
Measurement modes |
| Centerpoint | Yes |
| Center box (area, min/max, average) | In software only |
| Advanced on-board analysis functions | No |
| User defined field/text annotations | No |
| Automatic hot and cold spots | No |
Image presentation |
| Digital display | 3.5" High Resolution LCD |
| Video output | No |
| Palettes | 4 |
Optional lenses |
| 54 mm Telephoto | No |
| 10.5 mm Wide angle lens | No |
Image and data storage |
| Storage medium | SD memory card (2 GB), stores at least 1200 fully radiometric (.is2) IR-Fusion images or 3000 basic IR images (.bmp or .jpg) |
| On imager file formats | IS2, JPEG, BMP |
| Direct download capability | Mini USB download direct to PC |
| File formats supported in software | IS2, BMP, JPG, GIF, PNG, TIF, WMF, EXIF and EMF |
Imager features |
| Fully radiometric | Yes |
| Flash and torch light | No |
| Laser pointer | Yes |
| Windows based navigation menu | Yes |
| AutoCapture (Programable Image Capture) | No |
| 180º articulating lens | No |
| Software included | Yes (SmartView) |
Environmental and mechanical design |
| Operating temperature | -10 to +50°C (14 °F to 122 °F) |
| Storage temperature | -20 to +50°C (-4 °F to 122 °F) without batteries |
| Relative humidity | 10% to 95% non-condensing |
| Water and dust resistant | IP54 |
| Weight (including batteries) | .726kg (1.63 lb) |
| Camera size (HxWxD) | 28.4 x 8.6 x 13.5 cm (11.2 x 3.4 x 5.3 in) |
| Warranty | 2 years |
Power |
| Battery type | One lithium ion rechargeable smart battery pack with five-segment LED display to show charge level |
| Battery operating time | 4+ hours continuous per battery pack |
| Battery re-charge time | 2 hours for full charge |
| AC operation (110/220 VAC, 50/60 Hz) | AC operation (110/220 VAC, 50/60 Hz) |
| Automatic shut down | Yes (user selectable ON/OFF) |
| Sleep mode | Yes (user selectable ON/OFF) |
Applications |
| Electrical distribution/power generation | Yes |
| In plant electrical | Yes |
| Electromechanical | Yes |
| Mechanical systems | Yes |
| Process monitoring and installations | Yes |
| Building diagnostics | Yes |
IR-Fusion Technology |
| IR-Fusion technology | No |
| Full thermal | Yes |
| Full visual light | No |
| AutoBlend™ | No |
| Picture in picture | No |
| Color alarm | No |
Temperature measurement |
| Temperature range | -20 °C to 350 °C in 2 ranges (-4 °F to 662 °F in 2 ranges) |
| High temperature option | No |
| Accuracy | ±2 °C or 2% whichever is greater |
| Emissivity correction | Yes |
