| Other Features | |||||||||
 | Detector size | 160 x 120 | |||||||
| Detector type | Uncooled microbolometer, focal plane array | |||||||
| Field of view (FOV) | 22.5º horizontal x 31º vertical | |||||||
| Spatial resolution (IFOV) | 3.39 mRad | |||||||
| Minimum focus distance | 15.25 cm (approx. 6 in) | |||||||
| Thermal sensitivity (NETD) | ≤0.08 °C at 30 °C (100 mK) | |||||||
| Detector data acquisition/ ###Image frequency | 9 Hz | |||||||
| Focus | IR-OptiFlex™ focus system | |||||||
| IR digital zoom | No | |||||||
| Spectral band | 7.5 µm to 14 µm | |||||||
| Transmission correction (On Imager) | Yes | |||||||
| Reflected background temperature correction (On Imager) | Yes | |||||||
| Measurement modes | |||||||||
| Centerpoint | Yes | |||||||
| Center box (area, min/max, average) | Yes | |||||||
| User defined spots/boxes | Three on camera | |||||||
| Advanced on-board analysis functions | No | |||||||
| User defined field/text annotations | No | |||||||
| Voice annotation | Yes | |||||||
| Automatic hot and cold spots | Yes | |||||||
| Image presentation | |||||||||
| Digital display | 3.5" High Resolution LCD | |||||||
| Video output | Streaming USB video output(infrared, visible and IR-Fusion Modes) | |||||||
| Palettes | 16 | |||||||
| Optional lenses | |||||||||
| 54 mm Telephoto | No | |||||||
| 10.5 mm Wide angle lens | No | |||||||
| Image and data storage | |||||||||
| Storage medium | SD memory card (2 GB), stores at least 1200 fully radiometric (.is2) IR-Fusion images or 3000 basic IR images (.bmp or .jpg) | |||||||
| On imager file formats | IS2, IS3, JPEG, BMP, AVI | |||||||
| Direct download capability | Mini USB download direct to PC | |||||||
| File formats supported in software | IS2, IS3, BMP, JPG, GIF, PNG, TIF, WMF, EXIF and EMF | |||||||
| Imager features | |||||||||
| Fully radiometric | Yes | |||||||
| Flash and torch light | Yes | |||||||
| Laser pointer | Yes | |||||||
| Windows based navigation menu | Yes | |||||||
| AutoCapture (Programable Image Capture) | No | |||||||
| 180º articulating lens | No | |||||||
| Software included | Yes (SmartView) | |||||||
| Environmental and mechanical design | |||||||||
| Operating temperature | -10 to +50°C (14 °F to 122 °F) | |||||||
| Storage temperature | -20 to +50°C (-4 °F to 122 °F) without batteries | |||||||
| Relative humidity | 10% to 95% non-condensing | |||||||
| Water and dust resistant | IP54 | |||||||
| Weight (including batteries) | .726kg (1.63 lb) | |||||||
| Camera size (HxWxD) | 28.4 x 8.6 x 13.5 cm (11.2 x 3.4 x 5.3 in) | |||||||
| Warranty | 2 years | |||||||
| Power | |||||||||
| Battery type | Two lithium ion rechargeable smart battery packs with five-segment LED display to show charge level | |||||||
| Battery operating time | 4+ hours continuous per battery pack | |||||||
| Battery re-charge time | 2 hours for full charge | |||||||
| AC operation (110/220 VAC, 50/60 Hz) | AC operation (110/220 VAC, 50/60 Hz) | |||||||
| Automatic shut down | Yes (user selectable ON/OFF) | |||||||
| Sleep mode | Yes (user selectable ON/OFF) | |||||||
| Applications | |||||||||
| Electrical distribution/power generation | No | |||||||
| In plant electrical | No | |||||||
| Electromechanical | No | |||||||
| Mechanical systems | No | |||||||
| Process monitoring and installations | No | |||||||
| Building diagnostics | Yes | |||||||
| Electronics | No | |||||||
| Other | Yes | |||||||
| IR-Fusion Technology | |||||||||
| IR-Fusion technology | Yes | |||||||
| Full thermal | Yes | |||||||
| Full visual light | Yes | |||||||
| AutoBlend™ | Yes | |||||||
| Picture in picture | Yes | |||||||
| Color alarm | Yes (High temperature, low temperature, isotherm) | |||||||
| Temperature measurement | |||||||||
| Temperature range | -20 °C to 150 °C (-4 °F to 302 °F) | |||||||
| High temperature option | No | |||||||
| Accuracy | ±2 °C or 2% whichever is greater | |||||||
| Emissivity correction | Yes | |||||||
