73 561 400VNĐ
Specifications | ||
Vertical deflection | ||
Bandwidth | 60 MHz | |
Real-time sample rate | 625 MS/s | |
Channels | 2 | |
Number of scope inputs | 2 input channels plus external trigger | |
Rise Time | 5.8 | |
Accuracy | ± (2.1 % of reading + 0.04 x range/div) @ 5 mV/div to 100 V/div | |
Channel architecture | All inputs fully insulated from each other and from ground Inputs may be activated in any combination | |
Input coupling | AC or DC, with ground level indicator | |
Input sensitivity | 2 mV/div to 100 V/div, plus variable attenuation | |
Bandwidth limiter | User selectable: 20 kHz, 20 MHz or full bandwidth | |
Normal/invert/variable | On each input channel, switched separately | |
Input voltage | CAT III 1000 V/CAT IV 600 V rated | |
Input impedance | 1 MΩ ± 1 % // 14 pF ± 2 pF | |
Vertical resolution | 8 bit | |
Horizontal deflection | ||
Max. real-time sample rate (sampled simultaneously) | 625 MS/s for each channel | |
Record length | Up to 10,000 samples per channel | |
Time base range | 10 ns/div to 4 s/div | |
Time base in a 1-2-4-sequence Slower time/division settings using ScopeRecord Roll mode | ||
Glitch capture | 8 ns | |
Scope measurements | Cursor | 7 |
Automatic | 30 | |
Maximum Record length | ScopeRecord mode | 30,000 pts per input |
Scope mode | 10,000 pts per input | |
Timing accuracy | ± (0.01 % of reading + 1 pixel) | |
Meter Modes | ||
Meter inputs | Via 4 mm banana inputs, fully isolated from scope inputs and scope ground | |
Number of readings | One at a time | |
Maximum resolution | 5,000 counts | |
Input impedance | 1 MΩ ± 1 % // 14 pF ± 2 pF | |
Advanced meter functions | Auto/manual ranging, relative measurements (Zero reference), TrendPlot recording | |
Horizontal deflection | ||
Vdc accuracy | ± (0.5 % + 5 counts) | |
Vac true rms accuracy | 15 Hz to 60 Hz | ± (1 % + 10 counts) |
60 Hz to 1 kHz | ± (2.5 % + 15 counts) | |
Vac+dc true rms accuracy | 15 Hz to 60 Hz | ± (1 % + 10 counts) |
60 Hz to 1 kHz | ± (2.5 % + 15 counts) | |
Voltmeter ranges | 500 mV, 5 V, 50 V, 500 V, 1,000 V | |
Resistance | ||
Ranges | 500 Ω, 5 kΩ, 50 kΩ, 500 kΩ, 5 MΩ, 30 MΩ | |
Accuracy | ± (0.6 % + 5 counts) | |
Other meter functions | ||
Continuity | Beeper on < 50 Ω (± 30 Ω) | |
Diode test | Up to 2.8 V | |
Current (A) | Adc, Aac, Aac+dc using an optional current clamp or shunt Scaling factors: 0.1 mV/A, 1 mV/A to 100 V/A and 400 mV/A | |
Temperature | With optional accessories. Scale factors 1 °C/mV or 1 °F/mV |
